The Marlin 7 is the perfect trail companion and all-terrain riding companion with confidence-inspiring trail geometry. It offers the perfect balance of price and performance with an upgraded RockShox suspension fork that lets you ride fast over rocks and bumps, and the wide gear range of the SRAM SX Eagle 12-speed transmission.
Compra a plazos desde 3 cuotas mensuales
Frame:Alpha Silver aluminum, internal derailleur and telescopic seatpost routing, rack and kickstand mount, and 135x5mm ThruSkew thru axle
Frame material:ALUMINIUM
Rim size:27.5
Fork:RockShox Judy Silver, Solo Air spring, rebound adjustment, TurnKey hydraulic lockout, 42mm caster for 27.5" wheels, 100mm quick release, 100mm travel.
Tires:Maxxis Ardent Race, tubeless ready, EXO casing, folding rim, 60tpi, 27.5x2.40"
Front hub:Formula DC-20 LW, alloy, 6 bolts, 100x5 mm
Rear hub:Formula DC-22-22LW, 6 bolts, core Shimano 8/9/10, 135x5 mm
Rims:Bontrager Kovee, double wall, Tubeless Ready, 28 holes, 23 mm wide, Presta valve
Shift lever:SRAM
Rear derailleur:SRAM SX Eagle, 12-speed
Crankset:SRAM SX Eagle, 30D steel chainring, 49 mm chain line, 170 mm long.
Bottom Bracket:Truvativ Powerspline, 73mm, threaded cartridge, 118mm axle
Cassette:SRAM PG-1210 Eagle, 11-50, 12-speed
Chain:SRAM SX Eagle, 12-speed
Disc size:Max sizes from
Pedals:VP-536 nylon platform
Saddle:Bontrager Verse Short, stainless steel rails
Seatpost:TranzX JD-YSP18, 100 mm travel, internal guiding, 31.6 mm, 361 mm length
Handlebars:Bontrager aluminum, 31.8 mm, 15 mm height, 720 mm width
Stem:Bontrager Comp, 31.8 mm, 7 degrees, 35 mm length
Steering:Semi integrated, 1-1/8"
Grips:Bontrager XR Trail Comp with nylon lockout // Bontrager XR Trail Comp with nylon lockout
| Model year | 2025 |
|---|
| Frame material | Aluminium |
|---|---|
| Frame type | Unisex |
| Frame size | L |
| framesize | 45 |
| Fork | RockShox Judy Silver, muelle Solo Air, ajuste de rebote, bloqueo hidráulico TurnKey, avance de 46 mm para ruedas de 29", cierre rápido de 100 mm, recorrido de 100 mm. |
| headset_model | Semi integrado, 1-1/8" |
| Gears | SRAM SX Eagle, 12 velocidades |
|---|---|
| Shifters | SRAM SX Eagle, 12 velocidades |
| Rear derailleur | SRAM SX Eagle, 12 velocidades |
| Cassette | SRAM PG-1210 Eagle, 11-50, 12 velocidades |
| Chain | SRAM SX Eagle, 12 velocidades |
| Crankset | SRAM SX Eagle, plato de acero 30D, línea de cadena de 49 mm, longitud de 175 mm Truvativ Powerspline, 73 mm, cartucho roscado, eje de 118 mm |
| Wheels | Bontrager Kovee, doble pared, Tubeless Ready, 28 orificios, anchura de 23 mm, válvula Presta Formula DC-20 LW, aleación, 6 tornillos, 100x5 mm Formula DC-22-22LW, 6 pernos, núcleo Shimano 8/9/10, 135x5 mm |
|---|---|
| Tyres | Maxxis Ardent Race, tubeless ready, carcasa EXO, aro plegable, 60tpi, 29x2,40" |
| Front wheel size | 29 |
| Rear wheel size | 29 |
| Front brake | Shimano RT26, 6 tornillos, 180 mm // Shimano RT26, 6 tornillos, 160 mm Tamaños máximos del |
|---|---|
| Rear brake | Shimano RT26, 6 tornillos, 180 mm // Shimano RT26, 6 tornillos, 160 mm Tamaños máximos del |
| Handlebar | Bontrager de aluminio, 31,8 mm, altura de 15 mm, anchura de 750 mm |
|---|---|
| stem_model | Bontrager Comp, 31,8 mm, compatible con Blendr, 7 grados, longitud de 50 mm |
| bartape_or_grips_model | Bontrager XR Trail Comp con bloqueo de nylon // Bontrager XR Trail Comp con bloqueo de nylon |
| Saddle | Bontrager Verse Short, raíles de acero inoxidable |
| Seatpost | TranzX JD-YSP18, recorrido de 150 mm, guiado interno, 31,6 mm, longitud 470 mm |
| Reach | 47 |
|---|---|
| Stack | 61.8 |
| Head angle | 66.5 |
| Seat tube angle | 73.4 |
| Top tube length | 64.7 |
| Seat tube length | 45 |
| Head tube length | 11.5 |
| Chainstay length | 43.8 |
| Wheelbase | 119.7 |
| Standover height | 77.1 |
| Bottom bracket drop | 6 |
| bottom_bracket_height | 30.8 |
| Trail | 11 |
| Offset | 4.6 |
| Pedals | Plataforma de nylon VP-536 |
|---|
