Domane AL 5 Gen 4 by Trek. Reference: 80404.
Any questions about this product? Write or call us and we will be glad to help.
Shipping in 24/48 h for items in stock, or pick it up at our shop in La Unión (Murcia).
| Frame | Aluminio Alpha Serie 100, tubo de dirección perfilado, guiado interno, soportes para guardabarros, disco flat mount, UDH, eje pasante de 142x12 mm |
|---|---|
| Fork | Domane AL de carbono, tubo de horquilla perfilado de carbono, guiado interno de los cables de freno, soportes para guardabarros, disco flat mount, eje pasante de 12x100 mm |
| Wheels | Bontrager Paradigm 23, Tubeless Ready, 24 orificios, anchura de 23 mm, válvula Presta Bontrager de aluminio, rodamiento sellado, disco centerlock, eje pasante de 100x12 mm Bontrager de aluminio, rodamiento sellado, centerlock disco, núcleo Shimano de 11 v |
|---|---|
| Tyres | Bontrager Kwaremont Comp, Hard-Case Lite, aro de alambre, 60 tpi, 700x32 mm |
| Shifter | Shimano 105 R7120, 12 velocidades // Shimano 105 R7120, 12 velocidades |
|---|---|
| Front derailleur | Shimano 105 R7100, abrazadera de 31,8 mm, anclaje inferior |
| Rear derailleur | Shimano 105 R7100, piñón máx. 36T |
| Crank | Shimano 105 R7100, 50/34, longitud de 165 mm Shimano RS501 BSA |
| Cassette | Shimano 105 7101, 11-34, 12 velocidades |
| Chain | Shimano SLX M7100, 12 velocidades |
| Saddle | Verse Short Comp, raíles de acero, anchura de 145 mm |
|---|---|
| Seatpost | Bontrager Comp, aleación 6061, 27,2 mm, retroceso 8 mm, longitud 330 mm |
| Handlebar | Bontrager Comp, aluminio, 31,8 mm, avance de 80 mm, caída de 121 mm, anchura de las manetas de 40 cm, anchura extremos del manillar de 44 cm |
| Stem | Bontrager Elite, 31,8 mm, compatible con Blendr, 7 grados, longitud de 90 mm |
| Front brake | Shimano CL700, centerlock, 160 mm Tamaños máximos del |
| Rear brake | Shimano CL700, centerlock, 160 mm Tamaños máximos del |
| Reach | 37.4 |
|---|---|
| Stack | 57.5 |
| Head angle | 71.3 |
| Seat angle | 73.7 |
| Effective top tube | 54.2 |
| Seat tube | 50 |
| Head tube length | 16 |
| Chainstay length | 42 |
| Wheelbase | 101 |
| Standover | 75.4 |
| Bottom bracket drop | 8 |
| Trail | 5.9 |
| Offset | 5.3 |
| Model year | 2027 |
|---|
We reserve the right to make changes to the product information contained on this site at any time, without prior notice, including with regard to equipment, specifications, models, colours, materials and prices. Due to supply chain issues, compatible parts may be substituted at any time, without prior notice.
The weights of bikes and frames are based on painted frames at the pre-production stage at the time of publication. Weights may vary in final production.
