Trek Domane SL 5 Gen 5 Road Bike
Trek Domane SL 5 Gen 5 Road Bike
Trek Domane SL 5 Gen 5 Road Bike
Trek Domane SL 5 Gen 5 Road Bike
Trek Domane SL 5 Gen 5 Road Bike
Trek Domane SL 5 Gen 5 Road Bike
Trek Domane SL 5 Gen 5 Road Bike
Trek Domane SL 5 Gen 5 Road Bike
Trek Domane SL 5 Gen 5 Road Bike
Trek Domane SL 5 Gen 5 Road Bike

Domane SL 5 is a lightweight carbon endurance bike that blends all-day comfort with clean, modern simplicity.

Trek Domane SL 5 Gen 5 Road Bike

5347967
Agotado
Arrival date: 03/05/2027

€1,999.20 €2,499.00 -20%
Tax included
Color
  • Matte Deep Smoke
  • Buff Beige
  • Matte Nightshade
  • Matte Era White/Deep Smoke
Size
  • XS
  • S
  • M
  • ML
  • L
  • XL



Domane SL 5 is a lightweight carbon endurance bike that blends all-day comfort with clean, modern simplicity. Built from 500 Series OCLV Carbon, it features all-road 40mm tire clearance and a streamlined design that gets back to the essence of road riding. A 12-speed Shimano 105 drivetrain delivers precise shifting and a sleek riser bar adds comfort without cluttering your front end, making it ready for long miles, big days, and light gravel detours.

Specifications

Frameset

Frame500 Series OCLV Carbon, internal cable routing, integrated frame bag mounts, T47, integrated chain keeper, fender mounts, flat mount disc, UDH 142x12mm thru axle
ForkDomane SL carbon, tapered carbon steerer, internal brake routing, mudguard mounts, flat mount disc, carbon dropouts, 12x100 mm thru axle
Domane SL carbon, tapered carbon steerer, internal brake routing, fender mounts, flat mount disc, carbon dropouts, 12x100mm thru axle

Wheels

Front hubBontrager alloy, sealed bearing, CenterLock disc, 100x12 mm thru axle
Rear hubBontrager alloy, sealed bearing, CenterLock disc, Shimano 11-speed freehub, 142x12 mm thru axle
RimBontrager Paradigm 23, Tubeless Ready, 24-hole, 23 mm width, Presta valve
TyreBontrager Kwaremont Pro, Tubeless Ready, GR puncture protection, aramid bead, 120 tpi, 700x35 mm

Drivetrain

ShifterShimano 105 R7120, 12-speed
CranksetSizes XS, S: Shimano 105 R7100, 50/34, 160mm length
Sizes M, ML: Shimano 105 R7100, 50/34, 165 mm length
Sizes L, XL: Shimano 105 R7100, 50/34, 170 mm length
Bottom bracketPraxis, T47 threaded, internal bearing
CassetteShimano 105 7101, 11-34, 12-speed
ChainShimano SLX M7100, 12-speed

Components

SaddleVerse Short Comp, steel rails, 145 mm width
SeatpostBontrager carbon, 27.2 mm, 8 mm offset, 330 mm length
HandlebarSizes XS: Bontrager Comp Riser, alloy, 20 mm rise, 31.8, 70 mm reach, 36 cm width
Sizes S: Bontrager Comp Riser, alloy, 20 mm rise, 31.8, 70 mm reach, 38 cm width
Sizes M, ML: Bontrager Comp Riser, alloy, 20 mm rise, 31.8, 70 mm reach, 40 cm width
Sizes L, XL: Bontrager Comp Riser, alloy, 20 mm rise, 31.8, 70 mm reach, 42 cm width
StemSizes XS: Trek RCS Pro, -7-degree, 80 mm length
Sizes S: Trek RCS Pro, -7-degree, 90 mm length
Sizes M: Trek RCS Pro, -7-degree, 100 mm length
Sizes ML, L: Trek RCS Pro, -7-degree, 110 mm length
Sizes XL: Trek RCS Pro, -7 degree, 120 mm length
Brake rotorShimano CL700, CentreLock, 160 mm
Trek
2027-05-13

Frameset

FrameSerie 500 de carbono OCLV, guiado interno de cables, anclajes para bolsa de cuadro integrados, T47, protector de cadena integrado, anclajes de guardabarros, disco flat mount, eje pasante UDH 142x12 mm
ForkDomane SL de carbono, tubo de horquilla perfilado de carbono, guiado interno de los cables de freno, soportes para guardabarros, disco flat mount, punteras de carbono, eje pasante de 12x100 mm

Wheels

WheelsBontrager Paradigm 23, Tubeless Ready, 24 orificios, anchura de 23 mm, válvula Presta
Bontrager de aluminio, rodamiento sellado, disco centerlock, eje pasante de 100x12 mm
Bontrager de aleación, rodamiento sellado, centerlock disco, nucleo Shimano de 11 v
TyresBontrager Kwaremont Pro, Tubeless Ready, protección antipinchazos GR, aro de aramida, 120 tpi, 700x35 mm

Drivetrain

ShifterShimano 105 R7120, 12 velocidades // Shimano 105 R7120, 12 velocidades
CrankShimano 105 R7100, 50/34, longitud de 165 mm
Praxis, T47 roscado, rodamiento interno
CassetteShimano 105 7101, 11-34, 12 velocidades
ChainShimano SLX M7100, 12 velocidades

Components

SaddleVerse Short Comp, raíles de acero, anchura de 145 mm
SeatpostBontrager de carbono, 27,2 mm, retroceso de 8 mm, longitud de 330 mm
HandlebarBontrager Comp Riser, aleación, 20mm elevación, 31,8, 70 mm alcance, 40 cm anchura
StemTrek RCS Pro, -7 grados, longitud de 110 mm
Front brakeShimano CL700, centerlock, 160 mm
Tamaño máximo del di
Rear brakeShimano CL700, centerlock, 160 mm
Tamaño máximo del di

Geometry

Reach37.7
Stack59.6
Head angle71.9
Seat angle73.3
Effective top tube55.3
Seat tube53.3
Head tube length17
Chainstay length42
Wheelbase101
Standover80.5
Bottom bracket drop7.8
Trail6.3
Offset4.8

General info

Model year2027

We reserve the right to make changes to the product information contained on this site at any time, without prior notice, including with regard to equipment, specifications, models, colours, materials and prices. Due to supply chain issues, compatible parts may be substituted at any time, without prior notice.

The weights of bikes and frames are based on painted frames at the pre-production stage at the time of publication. Weights may vary in final production.
